Saturday, December 20, 2014

We would like to welcome Dixie Belle Paint to our family of clients. We have been commissioned to update their extensive catalog of products with professional true to color catalog shots on white sweep and compose a series of environmental shots showcasing the country craft quality of the product.

Primary line of  27 paints including colors like "Florida Orange" and "Flamingo"

Natural China hair brushes.

Shooting bottled product on a white sweep is not particularly difficult, but, keeping colors accurate can be a challenge. Here the black glaze is actually blue before the coating dries. Having a fully color calibrated equipment and workflow is the key to faithfully reproducing the unique colors in this or any other product line. Controlled lighting with a known color temperature, 6500°K, is only one part of the mix. A fully calibrated camera and workstation are also required.

Glazes and clear coats.

Glaze close up detail shot.

The camera is custom balanced to a standard gray card and also RGB values are calibrated to a known standard to keep the shots consistent across the entire range of hues and re-calibrated before each set change. The workstation is calibrated weekly with a colorimeter. We use only one workstation for final processing to eliminate any hardware variables that could slip into the process.

Kudzu green.

Kudzu green with neutral gray card.

The white sweeps are actually shot to light gray to stay consistent across the product line and allow the white colors to stand out more. There is more than enough separation to "knock out" the products if needed later.

Saturday, November 22, 2014

Often times I am asked to photograph interesting items for lobby and other displays. Here the owner of some interesting scale weights which I understand were once commonly used to weigh opium around the turn of the century in East Asia. The client commissioned me to create an art piece for the wall in his office.

After much arranging and fiddling around with the layout and lighting the client chose this photo which was further processed in Photoshop to achieve a subtle duo-tone effect to fit well with the colors and furnishings in the room. The total shots taken with different light and layout were around 250. Of which I chose the top 5 and the client chose the final image.

Lighting was ambient room light from a south facing window on a very overcast day giving wonderfully soft directional light from camera left and a few bright spots along the smooth worn areas of the bronze. A white fill card was added off camera right to bring some details into the shadows but still keep the shape definition of the pieces. The final print 22x16 inches does not have the watermark.

Nikon D90 105mm prime with a macro bellows
f/6 at 4 seconds ISO 400

See more examples on my Flickr page at

Monday, October 27, 2014

New Product Launch - Natural Sponge

The client is starting a new line of products on Amazon and has to be shot to Amazon's specs. Not the most glamorous work, but important. Not all jobs afford you the greatest creative latitude, sometime  you just shoot to spec.
Natural sponges are becoming all the rage after many years of declining sales. Tarpon Springs Sponge Docks ( is about the only place where sponge diving survives in the USA to this day and one of my favorite places to visit in the local area. So I was very happy to get the opportunity to shoot  this new line for Better Living Labs ( All the sponges are sourced and hand picked directly from vendors in this small community.

Local gift shop at the docks displays a variety
of Grass and other sponges

Sponges range in quality and variety from decorative Grass Sponges to the smaller tightly celled Wool Sponges used mostly in cosmetics and in the healthcare industry.

This may be a small job for the studio but it deserves all the care and attention demanded by our larger clients. The client wants the colorful packaging to shine and the quality of the product to come through for this series shot to Amazon's catalog specs. (shot on white sweep w/o any props). Here is a sample of the initial proofs.

Just a modest amount of post processing, basically
strait out of the camera.
With items like this I like to shoot with a light meter. Lots of white will fool the camera light sensor into under exposing the shot where an incidence meter can not be fooled.

And some of the finals...

Sponges on Amazon

Sunday, September 14, 2014

Artwork Reproduction

Another facet of the business is to photograph other peoples art , in this case, for reproduction as a color plate in biographical book about the artists of Woodstock, NY. The art must be evenly lit, show the texture of the medium in this case oil on canvas, be color accurate, and of course, be perfectly square with no distortions. The more you can get right in the camera; the less you'll have to do in post.

The painting is roughly 28"x34". Ideally I would use a 200mm lens and move back far enough to fill the frame of my D600 Nikon. Unfortunately this configuration is pushing me beyond the size limits of my small studio. The alternative is to switch to my 28-70mm set to 70mm and moving the camera to fill the frame. This will introduce a small amount of distortion which you would normally not notice but with a rectangular object close to the edges of the frame, its obvious but fixable in post.

Next problem is the sensor plane must be perpendicular to the canvas to prevent any keystone distortions. The painting is on an easel tilted back therefore the camera needs to be positioned high and tilted down.

Now that the camera and painting are in position, its time to bring in the lighting. Dried oil paints are very shiny and often have lots of texture which creates a lot of unwanted specular highlights. The goal is to get rid of the speculars but not loose the texture and brush strokes. This was solved by raising the key light very high and directly above the subject, moving most of the specular reflections below the angle of the camera and giving some relief to the texture because of the side lighting. Distancing the light source helps reduce the light fall off. The addition of a 40" silver reflector under the painting bounces just enough light back to the bottom to even out the lighting.

D600 24-70mm @70mm, 1/160, f/8, ISO 100
Artist: Nan Mason, 1932

Color correction done with a gray card along with minor contrast and distortion adjustments in post complete this project.

Monday, August 25, 2014

Antique Art

Part of what I do is to accurately reproduce antiques for auctions often times these drawings and sketches are behind glass making it difficult to photograph without reflections. Not only is the correct color important the art can not be distorted and must be photographed  perpendicular to the film/sensor plane. The only way to prevent reflections is to shoot in a darkened studio with lighting carefully placed as to not reflect back into the camera. In  this case the owner wanted the detail of  the pencil handwriting in the upper left and lower right photographed separately and ledgibly. The solution is to position the lights so they light the subject  but the light reflected off of the glass bounces off and away from the lens. By hanging the art on the wall and lighting from above with a large soft box the incident of reflection sends the reflected light to the non-reflective floor covered with black paper where most of the light is absorbed. Very little light is bounced into the studio leaving nothing to reflect.
Here are the finals after a small amount of contrast adjustment in Photoshop.

Saturday, August 9, 2014

The little jobs save the day!

Today I did  a shot of a client's father's wedding ring, exactly as given to the son, without any cleaning for insurance coverage.
Nikon D90 with a 55mm f2.8 Macro lens f8, 1/50 under LED lighting with white & black bounce cards.

Its little jobs like this that although, not exciting and glamorous, that pay the bills in the off season.

Friday, August 8, 2014

Antique Sorority Vases

I love shooting antiques and capturing the colors and patina they have. Here is an example of a simple shoot done for the client for a professional insurance appraisal. Kappa Kappa Phi vase pair valued between $600 and $700. Colors are rendered 100% true to life with no other editing. The lighting is a bit flat as these are for inspection purposes only. Note how the macro of the signature reveals the fine patina on the pottery.
Shot with a Nikon D600 24-70mm f/2.8 lens @ f5.6, 1/160sec, under studio strobes.
Macro shot with a Nikon D90 120mm f/2.8 and D4 bellows assembly. f/5.6, 1/160 sec.

Thursday, August 7, 2014

ProdPhoto Commercial Product Photography

In the midst of the summer months, I find myself in the quiet time before the holiday catalog and advertising crush, a great time to rekindle the urge to write.

First of all, let me introduce my company and what does. is a product photography shop that caters to new business and artists that want professional high end photography services but are new to what can often be the complex and expensive world of commercial photography. Usage licensing,  copyright issues, sample selection and preparation,  final image file type and sizing, and archiving are all simplified and direct. Above all ProdPhoto stays within your budget as little as $10 per finished image.

You tell us what you plan to use the images for and ProdPhoto will provide you with the original high resolution print files(TIFF format @240 dpi up to 24mpx) and any other format required, re-sized to fit your needs(ie. JPG @72 dpi suitable for the web). Fully cleaned up or "Photoshopped" images that render true colors and 1st class results.

Reproduction of artisan works which stay true to color, texture and proportion can be very difficult without the proper equipment. ProdPhoto's professionals use modern industry leading equipment and software to render your creations accurately. No color shifting, no spatial distortion only your design comes through.

90% of what ProdPhoto does is small tabletop items like jewelry, paintings, pottery and other similar items. The other 10%  are slightly larger items like clothing apparel, larger paintings and art pieces.

Well, that's it for today, I have run out of time and have to go into the studio and shoot some antique pottery. Be back soon!
